Mann Whitney U Test in SPSS: Easy Step-by-Step Guide

Researchers often face non normal data, ordinal scales, or small sample sizes that break t test assumptions. In such situations, the Mann Whitney U test in SPSS gives a reliable and defensible alternative for comparing two independent groups. Many students know the name of the test, yet struggle with correct execution, assumption checks, output interpretation, and effect size reporting.

This guide walks you through the full workflow using SPSS. You will learn when to choose the Mann Whitney U procedure, how to run it correctly, how to interpret each output table, and how to compute effect size. In addition, you will see reporting standards and applied research scenarios. Each section uses direct, active construction and clear transition logic so you can apply the method immediately in your thesis or journal work.

---

What the Mann Whitney U Test Measures

The Mann Whitney U test compares two independent groups using ranked scores instead of raw values. The procedure orders all observations, assigns ranks, and then evaluates whether one group tends to receive higher ranks than the other.

Unlike the independent samples t test, this method does not require normal distribution. For that reason, analysts often select it for skewed variables, Likert scale totals, and outlier heavy datasets.

Researchers typically use this test when they want to compare:

• Median or rank distributions
• Ordinal scale scores
• Non normal continuous measures
• Small sample group outcomes

Therefore, the Mann Whitney U test fits many applied survey and behavioral datasets.

---

When You Should Use Mann Whitney U Test in SPSS

You should select the Mann Whitney U test when your design and data structure meet specific criteria. Proper test selection strengthens validity and reduces reviewer criticism.

Choose this test under the following conditions.

Two independent groups must exist in your dataset. Each participant belongs to only one group. For example, gender groups, treatment vs control, or method A vs method B satisfy this rule.

Next, your dependent variable should appear as ordinal or continuous without normal distribution. Likert composites, rating scales, and skewed measurements qualify here.

In contrast, normally distributed interval data with equal variances support the independent samples t test instead. Always run normality checks before you decide.

As a result, analysts often run Shapiro Wilk tests and inspect histograms first, then move to Mann Whitney if assumptions fail.

---

Assumptions of the Mann Whitney U Test

Nonparametric tests still require assumptions. You should verify these conditions before running the procedure.

First, independence of observations must hold. Each case should contribute one score only. Repeated measures violate this rule. In that situation, you should use Wilcoxon signed rank instead.

Second, the grouping variable must contain exactly two categories. More than two groups require the Kruskal Wallis test.

Third, the dependent variable needs at least ordinal measurement level. Nominal categories do not support ranking logic.

Finally, both groups should show similar distribution shapes if you want to compare medians directly. When shapes differ strongly, the test detects distribution differences rather than median differences. Boxplots in SPSS help you verify this condition quickly.

---

How to Run a Mann Whitney U Test in SPSS

You can execute the Mann Whitney U test in SPSS through the legacy nonparametric dialog. The setup requires correct variable coding before analysis begins.

Start by confirming that your grouping variable uses two numeric codes only. For example, code Group as 1 and 2. Next, confirm that your outcome variable contains numeric values without text entries.

Then follow these steps.

Click Analyze, then choose Nonparametric Tests, then Legacy Dialogs, and finally select 2 Independent Samples.

After that, move your outcome variable into the Test Variable List box. Next, move your grouping variable into the Grouping Variable field.

Now click Define Groups and enter the exact two codes used in your dataset. Accuracy here prevents execution errors.

Then make sure the Mann Whitney U option remains selected. Finally, click OK to run the test.

SPSS will produce rank tables and a test statistics table for interpretation.

---

How to Interpret Mann Whitney U Test Output in SPSS

SPSS produces two primary tables. Each table answers a different interpretation question. Careful reading ensures correct conclusions.

Ranks Table Interpretation

The ranks table shows sample size, mean rank, and sum of ranks for each group. Higher mean rank indicates generally higher scores in that group.

You should use this table to determine direction of difference. However, statistical significance does not come from this table alone.

For example, if Group A shows a mean rank of 58 and Group B shows 42, then Group A tends to score higher on the outcome variable.

Test Statistics Table Interpretation

The test statistics table provides the Mann Whitney U value, the Z statistic, and the p value. These values determine significance.

Use this decision rule. When p falls below .05, you can conclude that a statistically significant difference exists between groups. When p stays above .05, you cannot claim a difference.

Always report the exact p value instead of a threshold statement only.

---

Effect Size for Mann Whitney U in SPSS

Effect size communicates practical importance, not just statistical significance. Many journals now expect this value in results sections.

SPSS does not display effect size automatically in the legacy output. You can compute it manually using the Z statistic.

Use this formula:

r = Z divided by square root of N

Here, Z comes from the test table. N equals total sample size across both groups.

For instance, suppose Z equals 2.40 and total N equals 100. The square root of 100 equals 10. The effect size r equals 0.24.

Interpretation guidelines follow common thresholds. A value near 0.1 indicates small effect. A value near 0.3 indicates medium effect. A value near 0.5 indicates large effect.

Therefore, always include r when you report Mann Whitney results.

---

How to Report Mann Whitney U Test Results

Clear reporting improves credibility and readability. Use standard statistical structure in your write up.

A correct example reads like this:

A Mann Whitney U test showed a significant difference in stress scores between the online group and the classroom group, U = 210.50, Z = −2.45, p = .014, r = .27.

Include the test name, U statistic, Z value, p value, and effect size. Also mention which group showed higher ranks or higher median.

Consistent formatting helps reviewers verify your conclusions quickly.

---

Practical Workflow for Correct Use

A structured workflow prevents common analytic mistakes. You can follow this sequence in most projects.

First, check measurement level of your dependent variable. Next, run normality tests and inspect plots. Then verify independence and group count.

After that, confirm two group coding accuracy in SPSS. Run the Mann Whitney U procedure. Review rank direction and p value together.

Subsequently, compute effect size and record it. Finally, report statistics with direction and context.

This structured approach supports defensible results.

---

Common Errors You Should Avoid

Several recurring mistakes weaken Mann Whitney analyses.

Some researchers apply the test to paired data, which breaks independence rules. Others use nominal outcomes that cannot support ranking.

Many reports include p values without direction information. Some analysts skip effect size completely. Incorrect group coding also produces invalid output.
